#concept

All data in computer programs are internally stored as bits, i.e., as numbers 0 and 1.

WhatsApp Image 2025-07-10 at 05.38.23.jpeg

In programming, an n-bit integer is internally stored as a binary number that consists of n bits. For example, the C++ type int is a 32-bit type, which means that every int number consists of 32 bits.

int n = 13;
cout << bitset<32>(n); // 000000000000000000000000000001101

The bits in the representation are indexed from right to left. From least significant to most significant bit.

To convert a bit representation $b_k\ldots b_2b_1b_0$ into a number, we can use the formula:

b_k2^k + \ldots + b_12^1 + b_02^0

Example:

1101 = 2^3 + 2^2 + 0*(2^1) + 2^0 = 8 + 4 + 0 + 1 = 13

The bit representation of a number is either signed or unsigned.

Generally, a signed representation is used, which means that both negative and positive numbers can be represented.

A signed variable of n bits can contain any integer between $-2^{n-1}$ and $2^{n-1}-1$

The int type in C++ is a signed type, so an int variable can contain any integer between $-2^{31}$ and $2^{31}-1$ .

1000\ldots0000 \text{ = INT\_MIN} = -2^{31} \, = -2147483648

0111\ldots1111 \text{ = INT\_MAX} = 2^{31} - 1 = 2147483647

The first bit in a signed representation is the sign bit of the number

0 for non-negative numbers
1 for negative numbers
and the remaining n−1 bits contain the magnitude of the number.

2's complement is used to represent a negative number is bits. Hence, 2's complement is used to calculate the value of a signed int with sign bit 1.

In an unsigned representation, only non-negative numbers can be used, but the upper bound for the values is larger.

In C++, an unsigned int variable can contain any integer between $0$ and $2^{32}-1$ .

There is a connection between the representations:

\text{signed int } -x = \, \text{ unsigned int }2^n-x

int x = -43
unsigned int y = -43;
cout << x << endl; // -43
cout << y << endl; // 429234234

If a number is larger than the upper bound of the bit representation, the number will overflow.

In a signed representation, the next number after $2^{n-1}-1$ is $-2^{n-1}$

In an unsigned representation, the next number after $2^n-1$ is $0$ .

int x = INT_MAX;
cout << x << endl; // 2147483647
x++;
cout << x << endl; // -2147483648

Common Bitwise Operators

AND Operation (`&`)

Intersection. Both bits must be 1.

\text{Decimal : } 5 \,\&\, 3 = 1

\text{Binary : }0101 \,\&\, 0011 = 0001

OR Operation (`|`)

Union. Any one bit should be 1.

\text{Decimal : } 5 \,|\, 3 = 7

\text{Binary : }0101 \,|\, 0011 = 0111

XOR Operation (`^`)

Xor of odd 1's is 1. Even 1's is 0.

\text{Decimal : } 5 \,\oplus\, 3 = 6

\text{Binary : }0101 \,\oplus\, 0011 = 0110

NOT Operation (`~`)

Flips all bits of a number.

\text{Decimal : } \sim 5 = -6

\text{Binary : } \sim 0101 = 1010 \text{ (read in 2's complement)}

Left Shift Operation (`<<`)

Shifting left multiplies the number by 2 for each shift.

\text{Decimal : } 5 \, \ll \, 1 = 10

\text{Binary : } 0101 \, \ll \, 1 = 1010

\text{Formula : } n \, \ll \, k = n \times 2^k

If you shift a number too far to the left (beyond its bit capacity), the sign bit may change, making the number negative. Resulting in unexpected outputs.

Right Shift Operation (`>>`)

Shifting right divides the number by 2 for each shift.

\text{Decimal : } 5 \, \gg \, 1 = 2

\text{Binary : } 0101 \, \gg \, 1 = 0010

\text{Formula : } n \, \gg \, k = \frac{n}{2^k}

1's Complement

The 1's complement of a binary number is obtained by flipping all the bits.

\text{Binary: } 0000\ldots0001011

\text{1's Complement: } 1111\ldots1110100

int n = 5; // Binary: 0...0101
int onesComplement = ~n; // Binary: 1...1010 : -6

2's Complement

The 2's complement of a binary number is obtained by taking the 1's complement of the number and then adding 1 to the result.

It is commonly used to represent negative integers in binary form.

\text{Binary: } 0\ldots0101

\text{1's Complement: } 1\ldots1010

\text{2's Complement: } 1\ldots1011

For positive integers, the 2's complement representation is the same as their binary form.

int n = 5; // Binary: 0...0101
int twosComplement = ~n + 1; // Binary: 1...1011 : -5

Common Properties

X \wedge 0 = X

X \wedge 1 = \textasciitilde X

X \wedge X = 0

X \,\&\, 0 = 0

X \,\&\, 1 = X

X \,\&\, X = X

X \,|\, 0 = X

X \,|\, 1 = 1

X \,|\, X = X

Programs

Swap two numbers

int a = 5;
int b = 3;

a = a ^ b;
b = a ^ b;
a = a ^ b;

/*
OR
a = a + b;
b = a - b;
a = a - b;
*/

cout << a << endl;    // 3
cout << b << endl;    // 5

Decimal to Binary Conversion

(13)_{10} = (1101)_2

string decimal_to_binary(int n = 13) {
	string binary = "";
	while(n)
	{
		binary += (n & 1) ? '1' : '0';
		n /= 2;
	}
	reverse(binary.begin(), binary.end());
	return binary;
}

Binary to Decimal Conversion

(1101)_2 = (13)_{10}

int binary_to_decimal(string binary = "1101") {
    int decimal = 0;
	int n = binary.size();
    for (int i = 0; i < n; i++)
        if (binary[n - 1 - i] == '1')
            decimal += pow(2, i);
    return decimal;
}

Get $i$ th Bit

int bit = (num >> i) & 1;
/* OR */
int bit = num & (1 << i);

Set $i$ th Bit

int newNum = num | (1 << i);

Clear $i$ th Bit

int newNum = num & (~(1 << i));

Toggle $i$ th Bit

int newNum = num ^ (1 << i);

Find last set bit (rightmost)

2's compliment flips all bits to the left of the rightmost bit. Which means, AND operation between a number and it's 2's compliment results in the rightmost set bit mask.

int n = 12;    // 00...01100
int x = ~n;    // 11...10011
x = x + 1;     // 11...10100
return n & x;  // 00...00100
/* OR */
return n & -n;

Similarly you can perform same operation on ~n instead to find rightmost unset bit.

Remove last set bit (rightmost)

If you take a number down by one, it's rightmost bit turned to zero. And all 0s to its right, get turned into 1s.

int n = 12;    // 1100
n - 1 = 11;    // 1011
return n & (n - 1); // 1000

To Check if $n$ is a Power of 2

An integer $n$ is a power of 2 if there is only one set bit in its binary representation.

bool isPowerOfTwo(int n) {
    return (n & (n - 1)) == 0;
    /* OR */
    return floor(log2(n)) == ceil(log2(n));
}

To Check if $n$ is a Power of 4

An integer $n$ is a power of 4 if it is a power of 2 and it's previous number is divisible by 3.

bool isPowerOfFour(int n) {
    return (n & (n - 1)) == 0 && (n - 1) % 3 == 0;
    /* OR */
    return floor(log2(n)) == ceil(log2(n)) && (int(log2(n)) % 2 == 0);
}

Count Set bits

int n = 28;
int count = 0;
while (n)
{
	n = n & (n - 1);
	count++;
}
return count;

STL

`std::bitset`

A class that provides an easy way to represent and manipulate fixed-size binary numbers.

bitset<8> b("1010");      // Binary representation: 1010
cout << b << endl;        // Output: 00001010

b.set(2);                 // Set the 2nd bit (0-based index)
cout << b << endl;        // Output: 00001110

b.reset(3);               // Clear the 3rd bit
cout << b << endl;        // Output: 00000110

b.flip();                 // Flip all bits
cout << b << endl;        // Output: 11111001

cout << b.count() << endl;  // Count the number of 1's (Output: 6)
cout << b.any() << endl;    // Check if any bit is set (Output: 1)
cout << b.none() << endl;   // Check if no bit is set (Output: 0)

int num = b.to_ulong();    // Convert bitset to unsigned long
cout << num << endl;       // Output: 249

`__builtin_popcount` and Variants

GCC/Clang built-in functions for fast bit-level operations.

__builtin_popcount(x): Counts the number of set bits in an integer.
__builtin_clz(x): Counts leading zeros.
__builtin_ctz(x): Counts trailing zeros.
__builtin_parity(x): Checks if the number of set bits is odd (returns 1 for odd, 0 for even).

int n = 13;  // Binary: 1101
cout << __builtin_popcount(n) << endl;  // Output: 3 (number of 1's)
cout << __builtin_clz(n) << endl;      // Output: 28 (leading zeros in 32-bit representation)
cout << __builtin_ctz(n) << endl;      // Output: 0 (trailing zeros)
cout << __builtin_parity(n) << endl;   // Output: 1 (odd number of 1's)
